Project Description

SOLAR PANELS

Green Energy From Solar Panels

Our wide range of solar panels and chargers provide you with an eco-friendly solution to supply a residential or commercial application with green energy. All solar panels are ideal for remote and isolated locations, saving the cost of running power mains wires. SPE’s panels combined with our specially designed intelligent battery chargers will have enough power to operate efficiently even during limited sunshine.

ENQUIRE HERE

Product Models

Solar Panels for Small Area Applications:

  • Residential Lighting
  • Community Buildings
  • Electronic Sliding and Swing Gates
  • Rural Supply for Water Pumping
  • Variable Messaging Signs for Motor Vehicles
Enquire

SP20

20 Watt monocrystalline solar panel. Ideal for electronic automatic gates and doors.

Maximum Power (Pm): 20 Watts
Voltage at Pm: 17.02V
Current at Pm: 1.16A
Open Circuit Voltage (VOC): 1.25A
Operating Temperature (°C): -40 to +85°C
Dimension (mm): 650 × 296 × 25
Weight (Kg): 2.5Kg

Enquire

SP40

40 Watt solar panel. 3.2mm tempered low iron glass, clear anodized aluminum alloy frame.

Maximum Power (Pm): 40 Watts
Voltage at Pm: 17.2V
Current at Pm: 2.33A
Open Circuit Voltage (VOC): 2.5A
Operating Temperature (°C): -40 to +85°C
Dimension (mm): 650 × 542 × 30
Weight (Kg): 4.5Kg

Enquire

SP60

60 Watt monocrystalline solar panel. High wattage for high duty cycle automatic gates.

Maximum Power (Pm): 60 Watts
Voltage at Pm: 18.00V
Current at Pm: 3.33A
Open Circuit Voltage (VOC): 3.55A
Operating Temperature (°C): -40 to +85°C
Dimension (mm): 840 × 542 × 30
Weight (Kg): 5.5Kg

Solar Panels for Large Area Applications:

  • Mining and Telemetry
  • Roadside Signage
  • Utility Scale Projects
  • Commercial, Schools and Community Buildings
  • Off Grid Systems for Homes, Hotels and Shops

180, 210 and 280 Watt solar panels. Suitable for Off-grid systems, hotels, resorts, homes and commercial buildings.

SP180

Maximum Power (Pm): 180 Watts
Voltage at Pm: 23.7V
Current at Pm: 7.60A
Open Circuit Voltage (VOC): 8.37A
Operating Temperature (°C): -40 to +85°C
Dimension (mm): 1318 × 994 × 46
Weight (Kg): 16.0Kg

Enquire

SP210

Maximum Power (Pm): 210 Watts
Voltage at Pm: 26.4V
Current at Pm: 7.95A
Open Circuit Voltage (VOC): 8.33A
Operating Temperature (°C): -40 to +85°C
Dimension (mm): 1482 × 992 × 35
Weight (Kg): 16.8Kg

Enquire

SP280

Maximum Power (Pm): 280 Watts
Voltage at Pm: 35.2V
Current at Pm: 7.95A
Open Circuit Voltage (VOC): 8.2A
Operating Temperature (°C): -40 to +85°C
Dimension (mm): 1956 × 992 × 50
Weight (Kg): 27Kg

Enquire

WE EXPORT WORLDWIDE

STATE OF THE ART FACILITY

FRIENDLY SALES TEAM

Solar Panels for Small Area Applications:

Model SP20 SP40 SP60
Maximum Power (Pm) 20 Watts 40 Watts 60 Watts
Voltage at Pm 17.02V 17.2V 18.00V
Current at Pm 1.16A 2.33A 3.33A
Open Circuit Voltage (VOC) 1.25A 2.5A 3.55A
Operating Temperature (°C) -40 to +85°C -40 to +85°C -40 to +85°C
Dimension (mm) 650 × 296 × 25 650 × 542 × 30 840 × 542 × 30
Weight (Kg) 2.5Kg 4.5Kg 5.5Kg

Solar Panels for Large Area Applications:

Model SP180 SP210 SP280
Maximum Power (Pm) 180 Watts 210 Watts 280 Watts
Voltage at Pm 23.7V 26.4V 35.2V
Current at Pm 7.60A 7.95A 7.95A
Open Circuit Voltage (VOC) 8.37A 8.33A 8.2A
Operating Temperature (°C) -40 to +85°C -40 to +85°C -40 to +85°C
Dimension (mm) 1318 × 994 × 46 1482 × 992 × 35 1956 × 992 × 50
Weight (Kg) 16.0Kg 16.8Kg 27Kg
